VTF-1 Listening Tests

System Setup

Setup of the VTF-1 itself will be straightforward for anyone who has owned a subwoofer before. On the presumption that an acoustically acceptable location has been preselected, place the sub and adjust the controls. Set the sub for either crossover bypass, for use as an LFE channel, or active and dial in a frequency appropriate to the roll off point of the accompanying main speakers. Next, using a full range source signal, flip the phase switch to the setting that produces higher output and finally adjust the level to balance the overall volume. If one likes to be more fancy, an SPL meter, or perhaps more sophisticated test gear, can be involved in the process, but this is, of course, up to user discretion.

Listening Evaluation

During the evaluation, I listened to the VTF-1 primarily using my A/V setup with the Toshiba HD-A2 as source, Rotel RSX-1067, and Infinity Beta speakers. For both film and dedicated music source material, the Rotel was used to provide bass management at a 60 Hz crossover point. Source material was reproduced in its native format, either multi-channel or stereo, with the Rotel set to two channel mode with stereo material and the Beta 40 towers engaged for the upper frequencies.

I was sent only a single VTF-1 for evaluation, which unfortunately allows more room acoustics issues to come into play than with the dual sub setup that I normally use. Locating the sub in a familiar position is the best way to minimize and accommodate this difference.

Editorial Note on Multiple Subwoofers

Multiple subwoofers are a good choice to smooth frequency response by minimizing room modal behavior through cancellation. Strategic placement of the subs at opposing nodal points for frequencies that trouble the listening area can be used to nullify the worst dips and peaks from the room modes. This is a distinct advantage over equalization, which can only trim peaks but not fill dips.

My own experience with running multiple subs has been a stark improvement with smoother frequency response, improved detail, and increased depth at the bottom beyond what a single well placed sub can muster.

I am including several links where this topic is discussed in greater detail and also an excel based room mode calculation spreadsheet:

Harman multsubs pdf

Getting the bass right pdf

Harman Room Mode Calculator.xls

I found the sonic character of the VTF-1 to be familiar based on previous experience with the STF-1. All of the sonic characteristics were similar but with a little more power, and when used in extension mode, notably more depth. Overall, the sound of the VTF-1 was musical, favoring a warm, rather than a lean, rendition of the bass output across its frequency response and able to provide a good level of resolution and inner detail. When comparing the sonic character with my reference gear, as with the STF-1, I would again describe a slight hollowness/looseness to the sound, but the VTF-1 was by no means boomy as the subwoofer maintained quick transient response and easily blended into the system with stable timbral characteristics of the instruments conveyed through the crossover point.

Unlike the STF-1, I did not encounter any port chaffing, but I did encounter the apparent excursion limits for the driver during some of the more intense sequences with movie soundtrack LFE when played at levels that I have become accustomed to with my reference subs. When used in the extension mode and subjected to the most demanding bass effects at high SPL, there would be an occasional, audible bottoming out of the cone. This limitation manifested itself as an audible pop(s), but when past the offending sound effects, the sub would continue on about its business.

To be fair with the context surrounding such events, the VTF-1 costs as much as the difference between the finish options of my reference sub.

Also in defense of the real world performance of the VTF-1, more recently, on Hsu’s website, they have started to provide a qualitative rating scale for subwoofer models relative to room size. The VTF-1 is considered adequate for moderate sized rooms according to this scale. While the area of the room where I evaluated the VTF-1 is not overly large, the open floor plan between rooms effectively shifts the requirements for subwoofer output into a range more consistent with a large area where one of the more powerful models might be appropriate.

Under the majority of circumstances, the driver fared well, playing deeper than typical of price competitive subs, with the VTF-1 giving little sign of distress up to the aforementioned limit; it stayed clean and gave no other audible signs of distress. A switch to high SPL mode, by simply pulling the plug and a flip of the switch, significantly alleviates the issue. Also, consider that this is the configuration that the manufacturer recommends, trading off extension when SPL demand is high such as with movie sound effects.

Do not mistake the apparent extension limit as a significant shortcoming when considering the price for which the VTF-1 is available and its’ likely competition. The difference with the Hsu sub is that the owner can choose the tradeoff as best suits taste and circumstance.

Batman Begins (HD-DVD)

Editorial Note on the Format War

I have made the leap of faith required by the format war and thrown in my lot with HD-DVD. The HD-DVD format, supported by the DVD Forum which incidentally was created to stave off the last format war that loomed before the dawn of DVD, is the only optical HD format released with a completed specification before hardware and software release, which foreshadows compatibility issues.

I dislike proprietary formats and certain unnamed companies have a long history of attempting to foist formats on consumers, hence: the format war. Despite the hype, the other format has certain omissions and shortcomings that I dislike such as additional layers of DRM to complicate functionality, annoying region codes, and a lack of mandatory support for HD audio formats.

For the readers who may disagree or who have chosen otherwise, I hope your gear still works correctly with new releases after the next specification update; good luck with that.

As Dolby Digital compression goes, I’ve found the audio quality of ‘Batman Begins’ to be of fairly good quality on the DVD release, but it is noticeably better on HD-DVD. Keeping in mind that few currently available processors have the capabilities for high definition/lossless digital audio transfer yet, even when mixed down from Dolby TrueHD to high bit rate DTS via SPDIF by the HD-A2, there is clear improvement in the spaciousness, the amount of detail, and the naturalness of the audio reproduction. Transcending the superhero genre, dramatically, ‘Batman Begins’ features a cleanly recorded score with potent deep sound effects and taut bass transients; a good subwoofer will allow one to fully appreciate what this film has to offer by way of audio.

I found that the VTF-1 was up to the task and made for enjoyable listening with this film. The VTF-1 portrayed the bottom end musically, giving depth and warmth to the intermingled strings and synthesizer parts used in the score. The theme, with its allegretto violins churning away martelé over a swelling of chords with a rich bottom end was always rendered tightly and with depth. I found that bass transients in various sound effects, percussion, and synthesizer parts were reproduced cleanly while still provided with weight, and when called upon by the score, this sub was capable of a solid bit of room rumbling.

Starting from the very beginning, the VTF-1 delivered tight orchestral bass transients as the picture opened and transients in the bass effects during flashback scenes of the well and bats throughout the movie were also crisp using this sub. Bruce Wayne’s trek up the mountain to the League of Shadows was provided with a controlled bottom end as the storm swirled around and the door to the compound opened and closed with audible weight. The various instances of driving percussion, used during the first fight and throughout the film, were allowed to generate a nice rumble through the VTF-1, which gave depth and solidity to the percussion part. While it did stumble with the loudest peaks at high SPL, the VTF-1 put up a good showing of the destruction of the compound, providing a good bit of meat and depth to the explosions. I also noted that the VTF-1 was able to provide the bat mobile with a satisfying engine throb as well as real weight to the monorail, which rumbled nicely as it passed. The score during the end credits again displayed the well balanced, musical capabilities of the sub, which kept the low orchestral and synthesizer parts distinguishable, revealing the inner workings of the music at the lowest octaves while still keeping character and warmth.

Babylon 5: Thirdspace (DVD)

With the DVD release of Babylon 5, I’ve found a surprising amount of deep bass in the remastered soundtracks, in both score and sound effects, which were not evident when I first watched on television. One of several movies interwoven into various subplots in the series, ‘Thirdspace’ considers the consequences of hubris when an ancient artifact is rediscovered in what has been likened to a space opera with overtones reminiscent of H.P. Lovecraft. As with the series, the score was written by Christopher Franke (Tangerine Dream) and performed by Franke on an array of enormous analogue synthesizers accompanied by the Berlin Philharmonic. For Babylon 5, Franke created a rich, definitive score that sustained mood for these stories about the price of struggle.

At the bottom end, the VTF-1 did justice to the soundtrack, conveying the depth and character of the synthesizer/orchestra combination while rumbling through the effects. Chords built and swelled, well founded on the VTF-1, which presented a warm, musical rendering at the lowest octaves of the score while dealing with the nearly continuous bass effects, and at all times remaining well connected with the main channels. From starship engines to the ever present low rumble of machinery on the station, the VTF-1 did its job well with few exceptions.

Throughout various scenes, the VTF-1 rumbled the room such as with the discovery of the artifact where deep, ominous chords built over the top of starship engines and currents of hyperspace, with each remaining distinct. The VTF-1 did well with the musical swells, delivering solid crescendos and decrescendos to my seat as well as my ears while maintaining depth and keeping the audio clean. Scenes of growing insanity and dark dreams were portrayed with weight and musically dark, with this sub capable of providing the right amount of heft in support. The sub also provided solidity to the subtle low frequency machinery that pervaded all the station scenes. Weapons fire was suitably staccato at the bottom and exploding starships shook the room as the climactic battle ensued. At the culmination, the sub did lose some composure under the demand of a nuclear detonation, but otherwise it put out a substantial amount of clean output during the battle. The closing score was musically solid and deep with the VTF-1 resolving and separating the low frequency string and synthesizer parts.

David Torn, Mick Karn, Terry Bozzio: Polytown

The result of a one time collaboration, ‘Polytown’ features the efforts of three notable rock musicians all with histories of delving into more experimental musical forms. Featuring guitarist David Torn, bassist Mick Karn, and drummer Terry Bozzio, it is a powerhouse of instrumental performance and musical talent. As challenging listen, these compositions are the type of unique and rewarding musical experience that is lost on music industry executives who are befuddled by anything that does not fit the prefabricated mould they are accustomed to hearing and that they think they can sell to the minions who support top forty styled music.

Throughout reproducing this album, the VTF-1 did a good job punching out Bozzio’s tight percussion, handling transitions with the mains, and putting meat on grinding fretless bass. On rare occasions, some of the percussion sounded slightly stressed, but to be fair, Terry Bozzio is not known for a particularly light touch on the drums and any hint of trouble only occurred when he was really belting it out. Bozzio can do an amazing amount of playing simultaneously, and with considerable zeal, but the VTF-1 was always able to keep up with the pace of the complex percussion. Other than the few aforementioned occasions, timbral character was well reproduced with low frequency ambience making its way out of the recording through the VTF-1.

Opening with ‘Honey Sweating’ the VTF-1 maintained the punch of the drums and percussion and the sub also kept the fretless bass taught, but still smooth, through transitions while maintaining accurate character. With ‘Open Letter to the Heart of Diaphora’, the VTF-1 pulled off a nice representation of the timbre of the low pitched toms opening the piece. The moving bass line was clean and well supported with a nice bit of rumble as the bass, drums, and guitars repeatedly converged and diverged through the undulating melody line. ‘Bandaged by Dreams’ again displayed good bass/bass drum punch, avoiding what easily can become one note-ism while still presenting the low end ambience captured in the recording. Some of the percussion did get a little heavy for the VTF-1 at volume during Karn’s bass clarinet solo, but Bozzio is doing some substantial pounding here. The VTF-1 also kept up with the torrent of percussion as ‘Warrior Horsemen of the Spirit Thundering over Hills of Doubt to a Place of Hope’ got underway. Throughout, the VTF-1 provided good punch and rumble at the bottom end and also managed to keep up with the triplet motifs superimposed over the bass drum pounding out the beat. Bass guitar on ‘Red Sleep’ was allowed to rumble throughout the piece with the VTF-1. Here, I found the sound through the VTF-1 to be clean, meaty, and well blended with the mains but still able to present low frequency ambient cues.

Peter Murphy: Dust

With the Middle Eastern laden ‘Dust’, Peter Murphy takes an experimental turn to explore a path conceptually reminiscent of certain other Peters (i.e. Peter Gabriel’s ‘Passion’). Placing general observation aside, Peter Murphy’s album stands on its own as a substantive work within the rock genera. ‘Dust’ is a musically dark, layered album full of various flavors of low instrumentation and percussion and seasoned with some tasty dissonance. The album provides many fine opportunities to expose the limits of a subwoofer’s capabilities.

Throughout, the VTF-1 was able to hold its own and get at the subterranean depths present in this recording, rumble the room, and still keep bottom end detail from collapsing into shapeless amorphism. When the recording called for bass weight, the VTF-1 was still able to keep the textures and layers at the bottom audible and integration with the main speakers stable.

The VTF-1 presented solid bass guitar and percussion on ‘Things to Remember’, deep enough to rumble the room but still clean and unstrained. The cello used in ’Fake Sparkle or Gold Dust’ was warm and detailed on the VTF-1 with a nice throaty bottom. ‘Just for Love’ was conveyed by the VTF-1 with the layered electronics and didgeridoo well separated and clean behind the tabla. As the song moves to a close, the sub continued to keep the increasing multi layered percussion separate from the drone at the bottom with the bass drum part presented as solid. Ambling percussion and bass opening ‘Girlchild Aglow’ showed off the integration maintained by the VTF-1 at the crossover. Bass chords were light, but were filled in by the sub, becoming meatier, as the song crescendos through this complex, arrhythmic part that plays counterpoint against the other instrumentation.
