Elemental Designs eQ.2 Parametric Equalizer Review
Summary
- Product Name: Elemental Designs eQ.2 Parametric Equalizer
- Manufacturer: Elemental Designs
- Performance Rating:
- Value Rating:
- Review Date: July 22, 2009 23:21
- MSRP: $ 85 w/ A7S $100 w/o A7S
- Specifications
-
EQ Type: Two band parametric
Frequency Bands: Continuous variable 10Hz - 50Hz, 50Hz - 100Hz
Band Width (Q): 0.3 - 3.0 Octaves
Level Adjustment: -15dB/+15dB
Subsonic Filter: Continuous variable 5Hz – 30Hz at 12 dB/octave w/ bypass
Phase Adjustment: Continuous variable 0 - 180 degrees
Dimensions: (HxWxD): 2.25" x 9.00" x 5.063"
Pros
- Inexpensive parametric equalization
- Does the job it is intended to do
Cons
- Manual tuning and measurement not for novices
- Limited precision due to physically small knobs
Introduction
The last several years have seen an increase of the number of options for room equalization at bass frequencies available to consumers. Following up on my A7S-450 review, I was asked to review an external parametric equalizer that Elemental Designs (eD) sells alongside its subwoofers. The eQ.2, can be purchased separately or as a bundle with one of the eD’s subwoofers at a slightly reduced price. The eQ.2 represents a usable parametric EQ solution but with some caveats. It is inexpensive and functional, but it is bare bones basic. For someone on a tight budget or the DIY types, the eQ.2 will certainly do the trick provided you take the time to set it up properly as I instruct in this review.
See also:
Recent Forum Posts:
Post Reply
theater_lover posts on July 26, 2009 23:22
I think these are fairly clever little boxes, certainly good for the price. I wished it supported two independent channels though.
lsiberian posts on July 23, 2009 15:03
admin;600459
The last several years have seen an increase of the number of options for room equalization at bass frequencies available to consumers. Following up on my A7S-450 review, I was asked to review an external parametric equalizer that Elemental Designs (eD) sells alongside its subwoofers. The eQ.2, can be purchased separately or as a bundle with one of the eD’s subwoofers at a slightly reduced price. The eQ.2 represents a usable parametric EQ solution but with some caveats. It is inexpensive and functional, but it is bare bones basic. For someone on a tight budget or the DIY types, the eQ.2 will certainly do the trick provided you take the time to set it up properly as I instruct in this review.
Discuss " Elemental Designs eQ.2 Parametric Equalizer Review" here. Read the article [audioholics.com].
Add this to an RCA line amp and you can use that to drive your subs.
GregBe posts on July 23, 2009 13:25
I bought an eQ.2 to go along with my SVS sub. For me, it was perfect. I had two really big peaks, one at 28hz and one at 63hz. Other than that, my response looked pretty good. Now with those two peaks tamed, my subs sounds terrific.
Post Reply
