Tripp Lite AV550SC UPS Power Block

OUTPUT

Output VA: 550

Output watts: 300

Output voltage regulation: BATTERY MODE - PWM sine wave output 120V +/-5%

Output frequency regulation: LINE MODE - passes line frequency of 60Hz +/-10%; BATTERY MODE: Inverter output regulated to 60Hz +/-0.5Hz

Outlet quantity / type: 4 NEMA 5-15R

Overload protection: 10-amp breaker

INPUT

Maximum input amps: 15A

Input connection type: Detachable 6" IEC320-C14 power cord

Recommended Electrical Service: 15A, 120V

BATTERY

Full load runtime: 3 minutes

Half load runtime: 10 minutes

DC system voltage: 12V DC

Typical battery lifespan: 3-6 years, depending on usage

Battery recharge rate: 15 hours (10% to 90% capacity)

LEDS ALARMS & SWITCHES

Front panel LEDs: 2 LEDs indicate power status and overload/check battery status

Switches: Includes 1 on/off push button (also acts as recycle/reset button)

SURGE / NOISE SUPPRESSION

AC surge suppression: 1038 joules

AC suppression response time: instantaneous

Dataline suppression: HD-compatible 2.2GHz coaxial and telephone/modem/DSL line surge protection

EMI / RFI AC noise suppression: Yes

Transfer time from line power to battery mode: 2-4 milliseconds

Low voltage transfer to battery power: Switches to battery power when line voltage decreases to 99 volts or less. Resets to line power mode when line voltage increases to 104 volts or higher.

High voltage transfer to battery power: Yes

PHYSICAL

Unit weight: 7.8 lbs

Unit Dimensions: 8.35" H x 6.78" W x 2.97" D

Cooling method: Convection

Certifications: 1778 (TUV) for US and Canada, NOM, FCC

Warranty: 2-years
