Emotiva Reference Theater Series IPS-1 Amplifier Review

150 Watts x 7 into 8 Ohms

200 Watts x 7 into 4 Ohms

Completely stable into 2 ohm loads

Each channel features independent 250VA, low noise toroid power transformers w/ high speed rectifiers and low ESR 105°C filter capacitors

High efficiency Class H power amplifier design, minimizes power losses and allows cool and efficient operation

Complementary, discrete power amplifier design incorporating high current, high speed, Toshiba power devices

RCA inputs

Silent turn on/off - No audible transients

THD less than .015%, 20Hz-20kHz with 80kHz measurement bandwidth

DC offset, less than 1mv, servo controlled.

Crosstalk between ANY two channels – greater than 120dB

All aluminum capacitors are premium quality, low ESR, 105°C rated for high reliability and performance

Doubled sided, plate through, glass epoxy, FR4 PCB’s used throughout with 2 ounce poured copper on all power sections and ground planes

Individual channel status indicators for standby, operate, and fault behind tinted acrylic panel

Fully protected from all fault conditions

Soft start circuitry

Signal sensing auto turn-on or remote 12 VDC trigger.

Soft touch power switch

3RU chassis w/ solid milled aluminum faceplate

IEC power inlet, 120/230 VAC user configurable

Dimensions: (HxWxD) 6” x 17.00 ” x 16 7/16"

Weight - 81 lbs.
