Sanyo PLV-Z4 Projector Review
Sanyo PLV-Z4
Summary
- Product Name: PLV-Z4 Projector
- Manufacturer: Sanyo
- Performance Rating:
- Value Rating:
- Review Date: February 25, 2006
- MSRP: $2995
- Specifications
-
Brightness: 1000 ANSI lumens (max)
Contrast: Up to 7,000:1 (stated full on/off)
Resolution: 1280 x 720 native HD resolution
Aspect Ratio: Widescreen native 16:9 aspect ratio (4:3 compatible)
Supported Screen Size: 40-300 inches diagonal
LCD Panel: D5 (Epson); 3 x 0.7” TFT Active Matrix LCD
Iris: Variable twin iris system (powered lens and lamp iris)
Accepted Video Formats: 480i/575i/1080i and 480p/720p
Accepted Computer Formats: From VGA up to 1152 x 900 + 720p/1080i
Video Inputs: HDMI-HDCP, component (x2), composite, S-video, and PC/RGB (HD15)
Color System: NTSC, PAL, SECAM, NTSC 4.43, PAL-M, PAL-N
Fan Noise: 22 dBaProjection Lens: 2.0x optical zoom; f = 21.3 – 42.6 mm/F2.0 – 3.0, manual focus & zoom
Lens Shift: Vertical and horizontal (100% vertical, 50% horizontal)
Keystone Correction: +/- 20 degrees
Lamp: 145 W UHP lamp
Mounting: ceiling, desk, front/rear (menu configurable)
Power Supply: 100-240 volts, 50-60Hz
Power Consumption: 210 watts (maximum
Operating Temperature: 41 – 95 degrees F (5 – 35 degrees C)
Projection Method: Front/rear/ceiling mount/table-top
Remote Control: Backlit, AA x 2 batteries
Standard Accessories: Power cord and adapter, Wireless remote control unit, batteries for remote control, owner’s manual
Operating Noise: 30dB (minimum)
Dimensions: 15” x 5” x 12” in. (382 x 126.8 x 304.3 mm)
Weight: 10.2 lbs (5 kg)
Pros
- Very detailed image
- Usable picture/color controls for HDMI input
- Extremely quiet
- 3000 hour bulb life (max)
- Excellent LCD panel adjustment and maintenance options
- Reduced screen door effect
Cons
- Requires calibration out of the box, specifically for white and black levels
- No 12VDC trigger
Introduction
- PLV-Z4 Build Quality & Inputs
- PLV-Z4 Menu System & Throw Chart
- PLV-Z4 Remote & Calibration
- PLV-Z4 Viewing Evaluation & Conclusion
